STEP TBC Models
It is widely used in logistics shipping and receiving distribution centers, ports, docks, stations, airports and warehouses. Involving industries of post, home appliances, food, tobacco and light industry. It saves time of walking back and forth to makes the loose loading work more efficient and less intensive.
Contact us for pricing information
Description
STEP TBC Models are conveyors designed with movable Dockless Telescopic Belt Conveyor with hydraulic lift that are custom built in 3 and 4 stages that makes it have an adjustable height from 6 meters up to 14 meters depending on which model you choose from that suits your production requirements.
Features:
• Suitable to handle all kinds of products
• Adjustable Height and Speed
• Various Length options
• Safe and Easy operation
• CE Certified Product
| Specifications: | |||||||
| STEP Item No. | Model | Base Length | Extended Length | Total Length | Belt Height Min. | Max. Load | Belt Speed m/min. |
| 47301010 | TBC 3S-4.5/6 | 4.500mm | 6meter | 10.5meter | 750mm | 50Kg/m | 15-30 |
| 47301020 | TBC 3S-6/8.5 | 6.000mm | 8.5meter | 14.5meter | 750mm | 50Kg/m | 15-30 |
| 47301030 | TBC 4S-6/12 | 6.000mm | 12meter | 18meter | 800mm | 50Kg/m | 15-30 |
| 47301040 | TBC 4S-7/14 | 7.000mm | 14meter | 21meter | 800mm | 50Kg/m | 15-30 |
Options:
• Initial dip noose inlet conveyor
• Robot pick up and load to conveyor
• Scanner functions
• Imaging functions
• Sorting system
• Palletizing
• Un palletizing
